SPECIFICATION
PVC, XLPE Insulation/Unshiled/Unarmored/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Copper tape shield/Unarmored/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Braiding shield/Unarmored/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Unshield/Galvanized steel tape armored/PVC, PE and LOSH sheath
PVC, XLPE Insulation/ Copper tape shield/Galvanized steel tape armored/PVC, PE and LOSH sheath
PVC, XLPE Insulation/ Unshield /Galvanized steel wire armored/PVC, PE and LOSH sheath
PVC, XLPE Insulation/ Copper tape shield/Galvanized steel wire armored/PVC, PE and LOSH sheath
| Application | Suitable for the interconnection in controlling, protecting and measuring system |
| Number of core | 2~61 cores |
| Rated Voltage | 450/750V conform to IEC 60227-2007 600/1000V conform to IEC 60502-2004 |
| Test Voltage | AC 3000V/5Min for 450/750V, AC 3500V/5Min for 600/1000V |
| Maximum conductor operating temperature | 90oC for XLPE insulation 70oC for PVC insulation |
| Core’s recognition | Up to 5 core with color Above 5 core with number |
| Color of sheath | Black and customer designated |
| Manufactured Standards | IEC 60227-2007, IEC 60502-2004 |
| Conductor type | IEC 60228-2004 class 1, class 2 and class5 Nominal Cross-section area:0.5~10mm2 We can produce according to your need and provide technical data. |
| Packing | Cable can be supplied in any length required. |
TYPE& SPECIFICATION
shielding and movability are required1.5 2.54-48
SERVICE CONDITIONS
(1) The long-time working temperature of conductor of PVC insulated cable is 70oC
The long-time working temperature of conductor of XLPE insulated cable is 90oC
(2) The temperature for laying the cables cannot be lower than 0oC.
(3) Permissible bending radius(r):
A. Unarmoured cable: r≥6D;(D: outer diameter of the cable);
B. Armoured or copper-tape screened cable: r≥12D;
C. Shielded flexible cable: r≥6D
